| 起源の場所: | 中国ニンポー |
| ブランド名: | Brando |
| 証明: | CE |
| モデル番号: | CA45FS |
| 最小注文数量: | 1セット |
|---|---|
| 価格: | Negotiation |
| パッケージの詳細: | 内部箱、カートン、パレット |
| 受渡し時間: | 4-9日 |
| 支払条件: | L/C、T/T、ウェスタン・ユニオン、Paypal |
| 供給の能力: | 1ヶ月あたりの100000 PC |
| 製品名: | CA45FS Goyenの取り替えの脈拍のジェット機弁 | 弁のタイプ: | フランジを付けたようになった弁 |
|---|---|---|---|
| 左舷サイズ: | 2"入口、1 1/2」の出口 | 関係: | Weldlessフランジ |
| 試験タイプ: | 必要な操縦者 | 電圧: | AC24V、AC110V、AC220V、DC12V、DC24V |
| ダイヤフラム材料: | NBR （ブナ） | ダイヤフラムの数: | 2 |
| 働き圧力: | 0.3MPa~0.8MPa | 環境の温度: | -5℃〜+ 55℃ |
| ハイライト: | Goyenのタイプ脈拍のジェット機弁,CA45FSの脈拍のジェット機弁,GoyenのタイプCA45FS |
||
Goyen Type CA45FS 1-1/2'' Flange Type Bag Filter Pulse Jet Valve
Description of FS Series Pulse Jet Valve:
High performance diaphragm valve with flanged inlet and sliding seal outlet for easy installation and removal. Available with integral pilot or remote control valve. The exit and entrance are at a 90 degree angle. "FS" series valves have 1 ", 1.5" port sizes. Applies to: Dust collector applications, especially for reverse pulse jet filter cleaning applications, including bag filters, cartridge filters, envelope filters, ceramic filters and sintered metal fiber filters.
YouTube video of CA45FS Goyen Replacement Dust Collector Pulse Valve:
Techincal data of Goyen type FS series Dust Collector Diaphragm Valve:
| Model No. | CA25FS | CA45FS |
| Operating Pressure | 0.3~0.8MPa | |
| Environment Temperature | -5~+55℃ | |
| Relative Humidity | ≤ 85% | |
| Working Fluid | Compressed air | |
| Voltages | AC24V, AC110V, AC220V, DC12V, DC24V | |
| Membrane Lifes | More than 1,000,000 times | |
| Orifice Diameter | φ25mm | φ45mm |
| Port Sizes | 1 1/2'' In, 1" Out | 2'' In, 1 1/2'' Out |
Overall dimension of 1 1/2 Inch Dust Collector Pulse Solenoid Valve:
Spare part pictures of CA45FS Reverse Pulse Jet Solenoid Valve:
Construction:
1. Body: Diecast Aluminium
2. Ferrule: 304 SS
3. Armature: 430FR SS
4. Seals: Nitrile or Viton (reinforced)
5. Spring: 304 SS
6. Screws: 302 SS
7. Outlet Slide Seals: EPDM or Viton
8. Diaphragm Seat: PA-6 (standard), Viton coated mild steel
Features:
1. Range of sizes and configurations for flexibility in system specification.
2. Engineered and tested for optimal performance and durability.
3. Reduced number of valve fittings necessary.
4. Solenoid coils available in standard AC and DC voltages.
5. Complies with current regulations.
6. Spare parts kits readily available.
Five tips for extending the life of Goyen type FS series flange connection pulse jet valve for dust collector bag filter:
1. First ensure that the voltage of the dust collector pulse jet valve is stable when in use.
2. The air supply pressure of the dust collector must be too low or the dust source is unstable. Before use, it is necessary to check the wiring line of the dust removal trouble regularly.
3. Replace the defective dust collector pulse jet valve parts in time. In the environment with temperature difference, the dust collector pulse jet valve should be used with the oil water separator.
4. The newly installed dust collector first cleans the solder joint impurities in the air bag.
5. Ensure that the clean air temperature of the valve body entering the dust collector pulse jet valve is not lower than -5 °C.
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
