| 起源の場所: | ナインボ,中国 |
| ブランド名: | BRANDO |
| 証明: | CE, ISO |
| モデル番号: | BC-24-1 |
| 最小注文数量: | 1pc |
|---|---|
| 価格: | negotiable |
| パッケージの詳細: | 箱,箱,パレット |
| 受渡し時間: | 4〜7 営業日 |
| 支払条件: | T/T,PayPal,ウェスタンユニオン |
| 供給の能力: | 5000PCS / 月 |
| 製品名: | パルスコントローラ | チャンネル番号: | 24 |
|---|---|---|---|
| 入力電圧: | 110VAC | 出力電圧: | 110VAC |
| パルス幅: | 0.01から99.99秒 | パルス間隔: | 1から999まで |
| サイクルの間隔: | 1から999まで | 適用する: | 集じん器 |
| ハイライト: | Pulse Controller 24 Lines,Pulse Controller 110VAC,Dust Collector Controller |
||
24 Lines 110VAC Input 110VAC Output Pulse Valve Controller For Dust Collector
Pulse Controller is a pulse jet bag filter control device in cleaning system, its output signal to control Pulse Jet Valve, blow compressed air bag sequential cleaning, so dust remains in the design within a predetermined range, in order to protect the processing power and dust collecting effect.
1. Channel Number: the number of pulse valves in the equipment (off-line mode is the number of pulse valves in a single chamber);
2. Pulse Width: the working time of the pulse valve (blowing time);
3. Pulse Interval: the interval between 2 pulse valves;
4. Cycle Interval: the interval between the end of one cycle and the start of the next cycle;
Technical Data:
| Model No | BC-08 | BC-10 | BC-12 | BC-16 | BC-20 | BC-24 | BC-30 | BC-36 | BC-52 | BC-64 |
| Channel No | 8 | 10 | 12 | 16 | 20 | 24 | 30 | 36 | 52 | 64 |
| Input Voltage | 24VDC, 110VAC, 220VAC, other can be customized | |||||||||
| Output Voltage | 24VDC, 24VAC, 110VAC, 220VAC, other can be customized | |||||||||
| Pulse Width | 0.1 to 999.9 Seconds | |||||||||
| Pulse Interval | 1 to 9999 Seconds | |||||||||
| Cycle Interval | 1 to 9999 Seconds | |||||||||
| Working Environment | 1. -25°C to +55°C 2. The relative humidity of the air does not exceed 85% 3. No serious corrosion gas and conductive dust 4. No violent vibration or shock |
|||||||||
Detailed Images:
Controller Setting:
Controller Wiring:
Our Production:
Related Products:
|
|
|
|
| Pulse Valve | Solenoid Coil | Solenoid Armature | Diaphragm |
