| 起源の場所: | ニンボ、中国 |
| ブランド名: | BRANDO |
| 証明: | None |
| モデル番号: | RCA25TD（2512） |
| 最小注文数量: | 8pcs |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 箱、カートン、パレット |
| 受渡し時間: | 4〜7 営業日 |
| 支払条件: | Paypal、ウェスタン・ユニオン、T/T |
| 供給の能力: | 月額50000個 |
| 製品名: | 脈拍のジェット機弁 | パイロットサイズ: | G1/8" |
|---|---|---|---|
| インレットサイズ: | G1」 | アウトレットサイズ: | 32mm OD、28mm ID |
| 横隔膜材料: | NBR (標準),FKM (オプション) | 圧力範囲: | 5〜125 psi |
| 応用: | 集じん器 | REF 番号: | RCA25TD000、RCA25TD200、RCA25TD010 |
| ハイライト: | GOYEN Pulse Valve RCA25TD,GOYEN Pulse Valve 2512,Dust Collector Pulse Jet Valve |
||
RCA25TD Goyen Type Pulse Valve
Pulse Jet Valve, also called diaphragm valve acts as a "switch" for compressed air in the dust collector system for bag filters. It is controlled by the electric signals from the Pulse Controller. Pulse Jet Valves are used in filtering systems of dust collectors, gas turbines, and desulfurization equipment. Pulse jet valves are commonly used to clean filters such as cartridge filters, envelope filters, ceramic filters, and sintered metal fiber filters.
Technical Data:
| Integral Pilot | CA15T | CA20T | CA25T | CA35T | CA45T | CA50T | CA62T | CA76T | CA20T4 | CA25T4 |
| Remote Pilot | RCA15T | RCA20T | RCA25T | RCA35T | RCA45T | RCA50T | RCA62T | RCA76T | RCA20T4 | RCA25T4 |
| Orifice Size (mm) | 15 | 20 | 25 | 35 | 45 | 50 | 62 | 76 | 20 | 25 |
| Port Size (Inch) | 1/2'' | 3/4'' | 1'' | 1-1/2'' | 1-1/2'' | 2'' | 2-1/2'' | 3'' | 3/4'' | 1'' |
| Pilot Size | 1/8'' | 1/4'' | 1/8'' | |||||||
| Diaphragm Number | 1 | 2 | 1 | |||||||
| Working Pressure | 5 to 125 psi | |||||||||
| Diaphragm Material | NBR (Standard), FKM (Oprtional) | Shockwave | ||||||||
| Body Material | Aluminum (diecast) | |||||||||
| Voltage | 24VDC, 24VAC, 110VAC, 220VAC | |||||||||
