| 起源の場所: | ニンボ、中国 |
| ブランド名: | BRANDO |
| 証明: | CE, ISO |
| モデル番号: | G353A041 |
| 最小注文数量: | 1PC |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 箱、カートン、パレット |
| 受渡し時間: | 4から7日 |
| 支払条件: | T/T、PayPal、Western Union |
| 供給の能力: | 1か月あたり10000pc |
| 製品名: | パルスバルブ | 構造: | 直角ポート |
|---|---|---|---|
| 手術: | リモートパイロット | パイロットサイズ: | G1/8′,G1/4′ |
| ポートサイズ: | G3/4'' | 横隔膜材料: | TPE |
| 使用圧力: | 0.35から8.5棒 | アプリケーション: | 集じん器 |
| ハイライト: | Pulse Valve G353A041,3/4'' Pulse Jet Valve,Pulse Jet Valve |
||
ASCO Type 3/4'' G353A041 Remote Pilot Diaphragm Pulse Jet Valve For Dust Collector
Pulse Jet Valve, also called diaphragm valve acts as a "switch" for compressed air in the dust collector system for bag filters. It is controlled by the electric signals from the pulse controller. Pulse jet valves are used in filtering systems of dust collectors, gas turbines, and desulfurization equipment. Pulse jet valves are commonly used to clean filters such as cartridge filters, envelope filters, ceramic filters, and sintered metal fiber filters.
Different pulse jet valve structure:
1. Right Angle Type
2. Compression Fitting Type
3. Full Immersed Type
4. Straight Through Type
5. Flanged Type
G353A041 Dimension:
Technical Data:
|
Port Size
|
Pilot Size
|
Orifice Size
(mm)
|
Kv
|
Operating Pressure Differential (bar)
|
Model Number
|
|
|
(m³/h)
|
(l/min)
|
|||||
|
threaded pipe connection
|
||||||
|
G3/4''
|
G1/8''
|
24
|
14
|
233
|
0.35 to 8.5
|
G353A041
|
|
G1''
|
G1/8''
|
27
|
17
|
283
|
0.35 to 8.5
|
G353A042 |
|
G1-1/2''
|
G1/4''
|
52
|
46
|
768
|
0.35 to 8.5
|
G353A045 (Single Stage) |
|
G1-1/2''
|
G1/8''
|
50
|
46
|
768
|
0.35 to 8.5
|
G353A046 (Double Stage) |
|
G2''
|
G1/4''
|
66
|
77
|
1290
|
0.35 to 8.5
|
G3530A48
|
|
G2-1/2''
|
G1/4''
|
66
|
92
|
1540
|
0.35 to 8.5
|
G353A049
|
