| 起源の場所: | 中国 |
| ブランド名: | BRANDO |
| 証明: | CE, ISO |
| モデル番号: | 276886 |
| 最小注文数量: | 5セット |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | ビニール袋、箱、カートン、パレット |
| 受渡し時間: | 3~5 営業日 |
| 支払条件: | T/T、ペイパル、ウェスタンユニオン |
| 供給の能力: | 1か月あたり100000セット |
| 製品名: | パルスバルブダイアフラム | 適合パルスバルブ接続口径: | 1 1/2 '' |
|---|---|---|---|
| フィットパルスバルブモデル: | 8353H038 | 横隔膜材料: | HYT（ハイトレル） |
| 色: | 白、黒 | 1セット: | 1x大きいダイヤフラム、1x小さいダイヤフラム、2xばね |
| ハイライト: | ASCO Diaphragm 276886,ASCO Diaphragm Replacement,HYT Pulse Valve Diaphragm |
||
276886 Hydrel Diaphragm Repair Kit For ASCO Pulse Jet Valve 8353H038
The diaphragm is the most important part of the pulse valve. When the pulse valve is energised, the trapped air above pulse valve diaphgram is quickly exhausted causing fast opening of main diaphragm valve. When the pulse valve is de-energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the pulse valve.
Overall Dimension of 276886 Diaphragm:
 |
|
| Main Diaphragm | Secondary Diaphragm |
Model No of Pulse Valve Diaphragm:
|
Integral Pilot
Pulse Valve
Model No
|
Remote Pilot
Pulse Valve
Model No
|
Pulse Valve
Port Size
|
Diaphragm Model |
Diaphragm
Model
(10 pack)
|
Diaphragm Material
|
|
-
|
8353C033
|
3/4''
|
96875
|
238864
|
NBR diaphragm
|
|
-
|
8353C030
|
3/4''
|
96875
|
238864
|
NBR diaphragm
|
|
-
|
8353C004
|
3/4''
|
96875
|
238864
|
NBR diaphragm
|
|
-
|
8353C035
|
1''
|
200262
|
238866
|
HYTREL diaphragm
|
|
8353G041
|
-
|
1''
|
316563
|
238866
|
HYTREL diaphragm
|
|
8353G006
|
-
|
1''
|
300144
|
-
|
CR diaphragm, PA disc
|
|
8353G005
|
-
|
1 1/4''
|
300144
|
-
|
CR diaphragm, PA disc
|
|
8353G001
|
-
|
1 1/2''
|
300144
|
-
|
CR diaphragm, PA disc
|
|
-
|
8353H038
|
1 1/2''
|
276886
|
238870
|
HYTREL diaphragm
|
|
8353J039
|
-
|
1 1/2''
|
322108
|
238870
|
HYTREL diaphragm
|
|
8353G061
|
-
|
1 1/2''
|
316297
|
-
|
NBR diaphragm, PA disc
|
|
-
|
8353A062
|
1 1/2''
|
276884
|
-
|
NBR diaphragm, PA disc
|
|
8353G002
|
-
|
2''
|
300145
|
-
|
CR diaphragm, PA disc
|
|
-
|
8353 048
|
2''
|
256802
|
256797
|
CR diaphragm
|
|
8353G050
|
-
|
2''
|
316029
|
256797
|
CR diaphragm
|
|
8353G007
|
-
|
2 1/2''
|
176878
|
-
|
CR diaphragm, PA disc
|
|
8353G008
|
-
|
3''
|
176878
|
-
|
CR diaphragm, PA disc
|
Our Production of Pulse Valve Diaphragm:
