| 起源の場所: | 中国 |
| ブランド名: | BRANDO |
| 証明: | CE, ISO |
| モデル番号: | C113825 |
| 最小注文数量: | 1セット |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | ビニール袋、箱、カートン、パレット |
| 受渡し時間: | 4〜7 営業日 |
| 支払条件: | L/C、T/T、Paypal、ウェスタン・ユニオン |
| 供給の能力: | 1か月あたり100000セット |
| 製品名: | パルスバルブダイアフラム | 注文コード: | C113825、C1138-25 |
|---|---|---|---|
| 横隔膜材料: | NBR、FKM | 1セット: | ダイヤフラム1個、スプリング1個。 |
| 適合パルスバルブ接続口径: | 1.5 '' | フィットパルスバルブモデル: | G353A045 |
| ハイライト: | ASCO Diaphragm C113825,ASCO Membrane C113825,C113825 Pulse Valve Diaphragm |
||
C113825 C113-825 Diaphragm Repair Kit For G353A045 ASCO Pulse Jet Valve 1.5''
C113825, C1138-25 Diaphragm (Membrane) for ASCO pulse valve G353A045; NBR material is standard, working temperature range is -5 to +80 ℃; Viton material is optional, for high temperature, working temperature range is -10 to +120 ℃. Pulse Jet Valve is a solenoid pilot operated diaphragm valve specially designed to deliver extremely fast pulsing in reverse-jet dust collector systems. With its high flow rates, higher peak pressure and the fastest response times on the market it delivers optimal filter cleaning performance, while using significantly less air. This results in energy savings for the user.
Ordering Number of Diaphragm For ASCO Pulse Valve:
|
Valve Port Size
|
Pulse Valve Model
|
Diaphragm Model
|
Diaphragm Material
(FKM is also available)
|
|
3/4''
|
SCG353A043
|
C113444
|
TPE (White), NBR (Black)
|
|
1''
|
SCG353A044
|
||
|
3/4''
|
SCG353-052
|
||
|
1''
|
SCG353-053
|
||
|
3/4''
|
SGG353A043
|
||
|
1''
|
SGG353A044
|
||
|
3/4''
|
SGG353-052
|
||
|
1''
|
SGG353-053
|
||
|
1 1/2''
|
SCG353A047
|
C113827
|
NBR
|
|
SGG353A065
|
|||
|
2''
|
SCG353A050
|
C113685, C113686
|
NBR
|
|
2 1/2''
|
SCG353A051
|
||
|
3''
|
SCXE353.060
|
C123432, C123433
|
NBR
|
|
SCG353D060
|
|||
|
3/4''
|
G3530A41
|
C113443
|
NBR
|
|
1''
|
G353A042
|
||
|
3/4''
|
G353-055
|
||
|
1''
|
G353-056
|
||
|
1 1/2''
|
G353A045
|
C113825
|
NBR
|
|
G353-066
|
|||
|
1 1/2''
|
G353A046
|
C113826
|
NBR
|
|
G353A063
|
|||
|
2''
|
G353A048
|
C113684
|
NBR
|
|
2 1/2''
|
G353A049
|
Main Dimension of C113825 Diaphragm:
Product Video of C113825 Membrane:
Pictures of Pulse Valve Diaphragm Production:
