| 起源の場所: | 寧波、中国 |
| ブランド名: | BRANDO |
| 証明: | CE, ISO |
| モデル番号: | C113826 |
| 最小注文数量: | 1セット |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | ビニール袋、箱、カートン、パレット |
| 受渡し時間: | 4〜7 営業日 |
| 支払条件: | T/T、ペイパル、ウェスタンユニオン |
| 供給の能力: | 1か月あたり100000セット |
| 製品名: | パルスバルブダイアフラム | 適切なパルスバルブモデル: | G353A046 |
|---|---|---|---|
| 横隔膜材料: | NBR、FKM | 1セット: | 1x大きいダイヤフラム、1x小さいダイヤフラム、2xばね |
| ハイライト: | ASCO C113826 Diaphragm,ASCO C113826 Membrane,ASCO Spare Parts Kit |
||
C113826 Diaphragm Replacement Kit For G353A046 ASCO 1-1/2'' Pulse Jet Valve
The diaphragm is the most important part of the pulse valve. When the pulse valve is energised, the trapped air above pulse valve diaphgram is quickly exhausted causing fast opening of main diaphragm valve. When the pulse valve is de-energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the pulse valve.
Ordering Code of Diaphragm For ASCO Pulse Valve:
|
Pulse Valve
Port Size
|
Pulse Valve
Model No
|
Diaphragm
Model No
|
Diaphragm Material
|
|
3/4''
|
SCG353A043
SCG353G043
SGG353A043
|
C113444
|
TPE, NBR, FKM
|
|
1''
|
SCG353A044
SCG353G044
SGG353A044
|
||
|
3/4''
|
SCG353-052
SCG353G052
SGG353-052
|
||
|
1''
|
SCG353-053
SCG353G053
SGG353-053
|
||
|
1 1/2''
|
SCG353A047
SCG353G047
SGG353A047
|
C113827
|
NBR, FKM
|
|
SCG353A065
SCG353G065
SGG353A065
|
|||
|
2''
|
SCG353A050
SCG353G050
SGG353A050
|
C113685, C113686
|
|
|
2 1/2''
|
SCG353A051
SCG353G051
SGG353A051
|
||
|
3''
|
SCG353D060
SCG353G060
|
C123432, C123433
|
|
|
3''
|
SCXE353.060
SCR353G060
|
C113928
|
|
|
3/4''
|
G353A041
|
C113443
|
TPE, NBR, FKM
|
|
1''
|
G353A042
|
||
|
3/4''
|
G353-055
|
||
|
1''
|
G353-056
|
||
|
1 1/2''
|
G353A045
|
C113825
|
NBR, FKM
|
|
G353-066
|
|||
|
G353A046
|
C113826
|
||
|
G353A063
|
|||
|
2''
|
G353A048
|
C113684
|
|
|
2 1/2''
|
G353A049
|
Dimension of C113826 Diaphragm:
 |
|
| Main Diaphragm | Secondary Diaphragm |
Pulse Valve Diaphragm Production Pictures:
