| 起源の場所: | 中国、ニンポー |
| ブランド名: | BRANDO |
| 証明: | CE, ISO |
| モデル番号: | M/D20 (AE18) |
| 最小注文数量: | 1台のパソコン |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | ビニール袋、箱、カートン、パレット |
| 受渡し時間: | 4〜7 営業日 |
| 支払条件: | T/T、ウェスタンユニオン、ペイパル |
| 供給の能力: | 1か月あたり100000個 |
| 製品名: | パルスバルブダイアフラム | 横隔膜材料: | TPE |
|---|---|---|---|
| 取り付けられたパルスバルブポート: | 3/4 '' | フィットパルスバルブモデル: | AE1818B、AE2818B |
| ハイライト: | AUTEL M/D20 Diaphragm,AUTEL M/D20 Membrane,AUTEL Pulse Valve Membrane |
||
M/D20 3/4" Diaphragm Repair Kit For AUTEL Type AE1818B AE2818B
The diaphragm is the most important part of the pulse valve. When the pulse valve is energised, the trapped air above pulse valve diaphgram is quickly exhausted causing fast opening of main diaphragm valve. When the pulse valve is de-energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the pulse valve.
Options for your customization:
1. Diaphragm Material: TPE, NBR, EPDM, FKM
2. Seat Material: Nylon, Rubber, PTFE
3. Diaphragm Color: Black, White, Red, Green, etc
4. Diaphragm Size: We can make it as same as your drawing
5. Packaging: We can provide you custom plastic bag with low MOQ
Ordering Code of Diaphragm For AUTEL Pulse Valve:
|
Diaphragm
Order Code
|
Diaphragm Reference No |
Pulse Valve
Model No
|
Pulse Valve
Port Size
|
Diaphragm
Material
|
|
AE18
|
M/D20
|
AE1818B, AE2818B
AE1822B, AE2822B
|
3/4'', 1''
|
TPE (Standard)
FKM+PTFE (High Temperature)
|
|
AE25
|
M/D25
|
AE1825B, AE2825B
AE1825R, AE2825R
|
1''
|
|
|
AE40
|
M/D40
|
AE1440B, AE2440B
AE1440R, AE2440R
|
1-1/2''
|
|
|
AE50
|
M/D50
M/D60
|
AE1450B, AE2450B
AE1460B, AE2460B
|
2'', 2-1/2''
|
|
|
AE75
|
M/D75
|
AE1475I12, AE2475I12
|
3''
|
Main Dimension of M/D20 Diaphragm:
![]()
Product Video of M/D20 Diaphragm:
Pictures of Solenoid Valve Membrane Production:
![]()
