| 起源の場所: | 中国 |
| ブランド名: | BRANDO |
| 証明: | None |
| モデル番号: | 0927100 |
| 最小注文数量: | 1台のパソコン |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 内箱、カートン、パレット |
| 受渡し時間: | 交渉 |
| 支払条件: | T/T、ウェスタンユニオン、マネーグラム |
| 供給の能力: | 100000個/月 |
| 接続口径: | 3/8" | オリフィスサイズ: | 10mm |
|---|---|---|---|
| アクション: | 作動する試験ダイヤフラム | メディア: | 水、空気、ガス、ライト オイル、等 |
| 本体材質: | 真鍮 | ダイヤフラム材質: | NBR、FKM、EPDM |
| 使用温度: | NBR （- +80ºCへの5）、EPDM （- +120ºCへの5）、FKM （- +150ºCへの10） | 圧力範囲: | 0.07から1.6 MPa |
| 電圧: | 12VDC、24VDC、24VAC、110VAC、220VAC | 関数: | 閉鎖した2方法普通 |
| ハイライト: | 0927100 3/8'' Brass Solenoid Valve,0927100 3/8'' Diaphragm solenoid valve,Air Compressor Brass Solenoid Valve 3/8'' |
||
0927100 3/8'' 2 Way 16 Bar Air Solenoid Valve BEST-NR.0200 24V 110V 220V
Product Features:
1. Working Medium: Water, Air, Gas, Light Oil, etc
2. Working Pressure Range: 0.07 to 1.6 MPa
3. Medium Temperature Range: NBR (-5 to +80ºC), EPDM (-5 to +120ºC), FKM (-10 to +150ºC)
4. Port Size: 1/4'', 3/8'', 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2''
5. Orifice Size: 8mm, 10mm, 12mm, 20mm, 25mm, 32mm, 40mm, 50mm
6. Body Material: Brass
7. Diaphragm Material: NBR, EPDM, FKM
8. Operation: Diaphragm Pilot Operated
9. Function: 2 Way Normally Closed, 2 Way Normally Open
10. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
Technical Data:
|
Model No
(2 Way NC)
|
0927000
|
0927100
|
0927200
|
0927300
|
0927400
|
0927500
|
0927600
|
0927700
|
|
Model No
(2 Way NO)
|
0955105
|
0955205
|
0955305
|
0955405
|
0955505
|
0955605
|
0955705
|
0955805
|
|
Orifice Size
(mm)
|
8
|
10
|
12
|
20
|
25
|
32
|
40
|
50
|
|
Port Size
(Inch)
|
1/4''
|
3/8''
|
1/2''
|
3/4''
|
1''
|
1 1/4''
|
1 1/2''
|
2''
|
|
Effective Area (mm²)
|
20
|
40
|
60
|
110
|
190
|
300
|
400
|
500
|
|
Function
|
2 Way Normally Closed: (0927 series)
2 Way Normally Open: (0955 series)
|
|||||||
|
Operation
|
Diaphragm Pilot Operated
|
|||||||
|
Working Pressure
|
0.07 to 1.6 MPa
|
0.1 to 1.6 MPa
|
||||||
|
Working Temperature
|
NBR: -5 to +80℃
EPDM: -5 to +120℃
FKM: -10 to +150℃
|
|||||||
|
Voltage
|
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
|
|||||||
Main Dimension:
|
Model No
|
Orifice Size
(mm)
|
Port Size
(Inch)
|
a
|
b
|
c
|
e
|
h
|
|
0927000
|
8
|
1/4''
|
45
|
31.5
|
22
|
53
|
97
|
|
0955105
|
114
|
||||||
|
0927100
|
10
|
3/8''
|
97
|
||||
|
0955205
|
114
|
||||||
|
0927200
|
12
|
1/2''
|
97
|
||||
|
0955305
|
114
|
||||||
|
0927300
|
20
|
3/4''
|
65
|
44
|
30
|
86
|
113
|
|
0955405
|
130
|
||||||
|
0927400
|
25
|
1''
|
113
|
||||
|
0955505
|
130
|
||||||
|
0927500
|
32
|
1 1/4''
|
95
|
47
|
31
|
131
|
136
|
|
0955605
|
153
|
||||||
|
0927600
|
40
|
1 1/2''
|
136
|
||||
|
0955705
|
153
|
||||||
|
0927700
|
50
|
2''
|
112
|
55
|
39.5
|
163
|
155
|
|
0955805
|
172
|
Our Production:
FAQ:
Question 1: What is a solenoid valve used for?
Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of applications.
Question 2: How can you tell if your solenoid is bad?
Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out coil, you need to troubleshoot the valve solenoids.
Question 3: How do I choose a solenoid valve?
Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, orifice size, temperature, pressure, voltage, response time and certification required for your application.
