| 起源の場所: | 寧波、中国 |
| ブランド名: | BRANDO |
| 証明: | None |
| モデル番号: | 6.16BAP030BM8 |
| 最小注文数量: | 200 |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 内箱、カートン、パレット |
| 受渡し時間: | 交渉 |
| 支払条件: | T/T、ペイパル、ウェスタンユニオン |
| 供給の能力: | 100000個/月 |
| 関数: | 普通閉まる2方法、 | 接続口径: | M8 |
|---|---|---|---|
| オリフィスサイズ: | 3mm | バルブボディ材質: | PTFE |
| シール材質: | PTFE | 使用圧力範囲: | 0〜0.3MPa |
| 電圧: | 12VDC、24VDC、110VAC、220VAC | ||
| ハイライト: | M8 PTFE Solenoid Valve,M8 Anti-corrosive PTFE Solenoid Valve,Anti Corrosion Solenoid Valve 24V |
||
M8 Anti-corrosive Isolation PTFE Solenoid Valve DC24V AC220V
Product Features:
Our isolation solenoid valves offer instrument designers a completely inert, non-metallic fluid path. The valves use a flexible diaphragm to isolate the solenoid actuation mechanism from the fluid path. Isolation Valves offer low internal volumes, precise flow control and excellent ease of installation making them particularly suitable for use in highly aggressive and / or high purity fluid applications such as analytical chemistry and clinical diagnostics. The highly inert fluid path is especially useful in liquid chromatography, genomics and protein synthesis applications. The high flow factor makes these valves well suited to environmental and water analysis applications.
Technical Data of Isolation Solenoid Valve:
| Model No. | Port size | Orifice (mm) | Cv | Mini Pressure | Max Pressure | Seal Material | |||
| AC(6VA) | DC(10W) | ||||||||
| 6.16BAP030BM8 | M8x1 | 3.0 | 0.1 | 0.0MPa | 0.3MPa | 0.3MPa | PTFE | ||
| 6.16BAP030B01 | 1/8'' | 3.0 | 0.1 | 0.0MPa | 0.3MPa | 0.3MPa | |||
| 6.16BAP030B02 | 1/4'' | 3.0 | 0.1 | 0.0MPa | 0.15MPa | 0.15MPa | |||
| AC(24VA) | DC(13W) | ||||||||
| 6.16BAP060B02 | 1/4'' | 6.0 | 0.28 | 0.0MPa | 0.15MPa | 0.15MPa | |||
| 6.16BAP060B03 | 3/8'' | 6.0 | 0.28 | 0.0MPa | 0.15MPa | 0.15MPa | |||
| 6.16BAP060B04 | 1/2'' | 6.0 | 0.28 | 0.0MPa | 0.15MPa | 0.15MPa | |||
| 6.16BAP060B06 | 3/4'' | 6.0 | 0.28 | 0.0MPa | 0.15MPa | 0.15MPa | |||
Main Dimension of Isolation Solenoid Valve:
