| 起源の場所: | 寧波、中国 |
| ブランド名: | BRANDO |
| 証明: | None |
| モデル番号: | 6.16DAP32B32 |
| 最小注文数量: | 200 |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 内箱、カートン、パレット |
| 受渡し時間: | 交渉 |
| 支払条件: | T/T、ペイパル、ウェスタンユニオン |
| 供給の能力: | 100000個/月 |
| 関数: | 普通閉まる2方法、 | 接続口径: | 1-1/4インチ |
|---|---|---|---|
| オリフィスサイズ: | 32mm | バルブボディ材質: | PTFE |
| シール材質: | EPDM,FKM,PTFE | 使用圧力範囲: | 0.01から0.6MPa |
| 電圧: | 12VDC、24VDC、110VAC、220VAC | 手術: | ピストン操縦者は作動した |
| 作動媒体: | 化学,酸,アルカリ,腐食性液体など | ||
| ハイライト: | PTFE Solenoid Valve 1-1/4'',Anti Corrosion Solenoid Valve 1-1/4'',Anti Corrosion Solenoid Valve 110v |
||
1-1/4'' PTFE Anti Corrosion Solenoid Valve for Acid Alkali Chemical
This is an anti corrosive PTFE solenoid valve, 1-1/4'' female threaded port size, 32mm orifice size, 2/2 way normally closed, pilot piston operated, 0.01 to 0.6 MPa working pressure, can be EPDM, FKM or PTFE seal to suit different working mediums, various voltages for your choice, such as 12VDC, 24VDC, 24VAC, 110VAC and 220VAC, etc. It is used for a wide arrange of industrial applications to control fluids.
Technical Data:
|
Model No
|
Port Size
|
Orifice Size
|
CV
|
Working Pressure
|
Body Material
|
Seal Material
|
Function
|
Voltage
|
|
6.16DAP15B04
|
1/2''
|
15mm
|
4
|
0 to 6 bar
|
PTFE
|
EPDM
FKM
PTFE
|
2 Way NC
|
12VDC
24VDC
24VAC
110VAC
220VAC
|
|
6.16DAP20B06
|
3/4''
|
20mm
|
5.5
|
|||||
|
6.16DAP25B25
|
1''
|
25mm
|
13
|
|||||
|
6.16DAP32B32
|
1-1/4''
|
32mm
|
17
|
|||||
|
6.16DAP40B40
|
1-1/2''
|
40mm
|
25
|
|||||
|
6.16DAP50B50
|
2''
|
50mm
|
40
|
|||||
|
6.16DAP65B65
|
2-1/2''
|
60mm
|
62
|
|
Model No
|
Dimension
|
||||||||
|
P
|
D
|
H
|
E
|
A
|
M
|
L
|
K
|
F
|
|
|
6.16DAP15B04
|
1/2''
|
70
|
127
|
56.5
|
18.5
|
M5
|
14
|
92
|
58
|
|
6.16DAP20B06
|
3/4''
|
80
|
136
|
70.5
|
20
|
M6
|
10
|
92
|
67
|
|
6.16DAP25B25
|
1''
|
95
|
145
|
78
|
25
|
M6
|
12
|
92
|
75
|
|
6.16DAP32B32
|
1-1/4''
|
120
|
200
|
110
|
31
|
M8
|
20
|
94
|
98
|
|
6.16DAP40B40
|
1-1/2''
|
130
|
220
|
113
|
33.5
|
M8
|
18
|
94
|
106
|
|
6.16DAP50B50
|
2''
|
150
|
249
|
140
|
43
|
M10
|
20
|
94
|
116
|
|
6.16DAP65B65
|
2-1/2''
|
180
|
262
|
152
|
49
|
M10
|
25
|
94
|
116
|
Our Production:
FAQ:
Question 1: What is a solenoid valve used for?
Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of applications.
Question 2: How can you tell if your solenoid valve is bad?
Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out solenoid coil, you need to troubleshoot the valve solenoids.
Question 3: How do I choose a solenoid valve?
Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, port size, orifice size, temperature, pressure, voltage, response time and certification required for your application.
