AirTac Type AF BF Series Filter AF1500 AF2000 BF2000 BF3000 BF4000

AirTac Type AF BF Series Filter AF1500 AF2000 BF2000 BF3000 BF4000

  • AirTac Type AF BF Series Filter AF1500 AF2000 BF2000 BF3000 BF4000
  • AirTac Type AF BF Series Filter AF1500 AF2000 BF2000 BF3000 BF4000
  • AirTac Type AF BF Series Filter AF1500 AF2000 BF2000 BF3000 BF4000
AirTac Type AF BF Series Filter AF1500 AF2000 BF2000 BF3000 BF4000
商品の詳細:
起源の場所: 中国
ブランド名: BRANDO
証明: None
モデル番号: AF、BF
お支払配送条件:
最小注文数量: 1PC
価格: 交渉可能
パッケージの詳細: 内箱、カートン、パレット
受渡し時間: 交渉
支払条件: T/T、ウェスタンユニオン、マネーグラム
供給の能力: 100000個/月
連絡先
詳細製品概要
製品名: パンネマティックエアフィルター 接続口径: 1/8"、1/4"、3/8"、1/2」
ろ過の等級: 40 μmか5 μm 証明圧力: 1.5MPa (215PSI)
温度範囲潤滑剤: -5~70℃(解凍) 下水管ボールの容量: 15CC、60CC
ハイライト:

AirTac BF Series Filter

,

Airtac BF Air Preparation Filter

,

AF BF Filter AirTAC

AirTac Type AF BF Series Filter AF1500 AF2000 BF2000 BF3000 BF4000


Product Features of AF, BF series Pneumatic Filter:


AF Series

1.The structure is delicate and compact.
2.The pressure loss is low and the efficiencyof water separating is high;
3.The filter precision includes 5μm and 40μm (optional);


BF Series

1.The pressure loss is low and the efficiency ofwater separating is high.
2.The bowl has high-strength plastic shields outside, which is more safe and reliable to use.
3.The filter precision includes 5μm and 40μm (optional).


Specification of AF, BF series Pneumatic Filter:

Model
AF1500
AF2000
BF2000
BF3000
BF4000
Fluid
Air
Port Size
1/8''
1/4''
1/4''
3/8''
1/2''
Filtering Grade
40μm or 5μm
Pressure Range
Semi-auto and automatic drain: 0.15 to 1.0 MPa (20 to 145 psi)
Manual drain: 0 to 1.0 MPa (0 to 145 psi)
Proof Pressure
1.5 MPa (215 psi)
Temperature Range
-5 to 70℃ (unfreeze)
Capacity of drain bowl
15CC
60CC


Ordering Code of AF, BF series Pneumatic Filter:

AirTac Type AF BF Series Filter AF1500 AF2000 BF2000 BF3000 BF4000 0


Dimension of AF, BF series Pneumatic Filter:

AirTac Type AF BF Series Filter AF1500 AF2000 BF2000 BF3000 BF4000 1

AirTac Type AF BF Series Filter AF1500 AF2000 BF2000 BF3000 BF4000 2


Inner Structure of AF, BF series Pneumatic Filter:

AirTac Type AF BF Series Filter AF1500 AF2000 BF2000 BF3000 BF4000 3

AirTac Type AF BF Series Filter AF1500 AF2000 BF2000 BF3000 BF4000 4


BRANDO Supply Filter Regulator Lubricator:


Filter Regulator Lubricator Airtac Type Filter Regulator Lubricator SMC Type Filter Regulator Lubricator Festo Type
AirTac Type AF BF Series Filter AF1500 AF2000 BF2000 BF3000 BF4000 5 AirTac Type AF BF Series Filter AF1500 AF2000 BF2000 BF3000 BF4000 6 AirTac Type AF BF Series Filter AF1500 AF2000 BF2000 BF3000 BF4000 7



Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing


Welcome to your any question and inquiry!
