| 起源の場所: | 中国 |
| ブランド名: | BRANDO |
| 証明: | None |
| モデル番号: | GT48 |
| 最小注文数量: | 1PC |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 内箱、カートン、パレット |
| 受渡し時間: | 交渉 |
| 支払条件: | T/T、ウェスタンユニオン、マネーグラム |
| 供給の能力: | 100000個/月 |
| 製品名: | パネウマティックピストン振動器 | 接続口径: | 3/8" |
|---|---|---|---|
| 定格周波数: | 6000から46000のRPM | 遠心力: | 130への12000 N |
| 使用温度: | 120℃まで | 長さ: | 194mm |
| 身長: | 120mm | 幅: | 86mm |
| ハイライト: | GT-48 Turbine Vibrator,GT Series Golden Turbine Vibrators,Turbine Vibrator GT48 |
||
GT48 3/8'' Pneumatic Turbine Vibrators Silent Golden Industrial Vibrator for Hopper Golden
GT Series Pneumatic Golden Turbine Vibrators require no air lubrication, and feature high frequency vibration, low noise output, and lower air consumption than other types of pneumatic roatry vibrators. They are ideal for applications in the food & pharmaceutical industries, and other applications involving fine, dry powders that respond well to high frequency vibration.
All GT Vibrators are constructed of lightweight extruded aluminum alloy bodies with hard coated turbine wheels and endplates, and pre-lubricated matched bearings for longer life. Standard GT Models use brass weights in the turbine; GT Models ending in “S” use heavy metal weights in the turbine for a lower frequency.
BRANDO offers 17 different models in the GT Series, with centrifugal forces to over 2300 pounds.
Main Dimension of GT Series Pneumatic Turbine Vibrators:
|
Model
|
A
(mm)
|
Width
(mm)
|
C
(mm)
|
D
(mm)
|
E
(mm)
|
F
(mm)
|
H
(Thread)
|
|
GT-4
GT-6
|
40
|
28
|
70
|
56
|
10.5
|
6
|
G1/8''
|
|
GT-8
GT-10
|
50
|
33
|
86
|
68
|
12
|
7
|
G1/8''
|
|
GT-13
GT-16
|
65
|
42
|
113
|
90
|
16
|
9
|
G1/4''
|
|
GT-20
GT-25
|
80
|
56
|
128
|
104
|
16
|
9
|
G1/4''
|
|
GT-30
GT-36
|
100
|
73
|
160
|
130
|
20
|
11
|
G3/8''
|
|
GT-40
GT-48
|
120
|
86
|
194
|
152
|
24
|
17
|
G3/8''
|
Technical Data of GT Series Pneumatic Turbine Vibrators:
|
Model
|
Vibrations
(x1000 RPM)
|
Centrifugal Force
(N)
|
Air Consumption
(l/min)
|
||||||
|
2 bar
|
4 bar
|
6 bar
|
2 bar
|
4 bar
|
6 bar
|
2 bar
|
4 bar
|
6 bar
|
|
|
GT-4
|
14.0
|
15.0
|
15.0
|
135
|
180
|
200
|
33
|
58
|
83
|
|
GT-6
|
11.5
|
12.0
|
12.5
|
130
|
175
|
210
|
|||
|
GT-8
|
36.0
|
42.0
|
46.5
|
990
|
2060
|
2910
|
46
|
80
|
112
|
|
GT-10
|
27.5
|
35.0
|
37.5
|
840
|
1390
|
2400
|
|||
|
GT-10-S
|
17.0
|
23.0
|
25.0
|
650
|
1350
|
1950
|
|||
|
GT-13
|
26.0
|
30.0
|
33.0
|
1400
|
2440
|
3730
|
120
|
200
|
290
|
|
GT-16
|
17.0
|
21.5
|
24.0
|
1220
|
2090
|
3160
|
|||
|
GT-16-S
|
11.5
|
15.5
|
17.0
|
1100
|
1900
|
2700
|
|||
|
GT-20
|
17.0
|
20.0
|
23.0
|
2170
|
4040
|
5520
|
185
|
325
|
455
|
|
GT-25
|
12.0
|
15.5
|
17.0
|
2120
|
3510
|
5070
|
|||
|
GT-25-S
|
8.5
|
11.0
|
13.0
|
2250
|
3600
|
4900
|
|||
|
GT-30
|
13.0
|
14.0
|
16.0
|
3380
|
5430
|
7540
|
330
|
530
|
745
|
|
GT-36
|
8.0
|
10.0
|
13.0
|
3290
|
5360
|
7190
|
|||
|
GT-36-S
|
6.1
|
7.2
|
8.3
|
4100
|
6200
|
7500
|
|||
|
GT-40
|
7.7
|
8.8
|
9.5
|
4300
|
7300
|
9800
|
425
|
700
|
970
|
|
GT-48
|
6.0
|
7.5
|
9.7
|
4900
|
7700
|
10500
|
|||
|
GT-48-S
|
-
|
5.6
|
6.3
|
-
|
7500
|
12000
|
|||
Construction of GT Series Pneumatic Turbine Vibrators:
