| 起源の場所: | 中国 |
| ブランド名: | BRANDO |
| 証明: | None |
| モデル番号: | K25 |
| 最小注文数量: | 1PC |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 内箱、カートン、パレット |
| 受渡し時間: | 交渉 |
| 支払条件: | T/T、ウェスタンユニオン、マネーグラム |
| 供給の能力: | 100000個/月 |
| 製品名: | パネウマティック・エア・ノッカー | 入口サイズ: | 3/8" |
|---|---|---|---|
| 排気のサイズ: | 3/8" | 本体材質: | アルミニウム合金 |
| 使用圧力: | 0.3から0.7MPa | 空気消費量: | 0.455 L/時間 |
| 衝撃力: | 19.3から29.5kgm/s | 正味重量: | 7.6kg |
| ハイライト: | SK Series Pneumatic Air Knocker,SK-Air Knocker,SEISHIN SK-80 Air Knocker |
||
SEISHIN Type SK-80 Air Knocker SK series SK80 Pneumatic Hammer
This is SK-80 air knocker similar to SEISHIN. Pneumatic air knocker keeps on hammering without a break to remove powder clogging and adhesion in hoppers and pipes, which are popularly used for many applications in fields such as manufacturing, food processing and pharmaceuticals.
Technical Data:
| Model No |
Working Pressure (bar) |
Air Consumption (L/Time) |
Wallop (kgm/sec) |
| SK-30 | 3 to 7 | 0.028 | ~0.75 |
| SK-40 | 3 to 7 | 0.082 | ~2.2 |
| SK-60 | 3 to 7 | 0.228 | ~7.4 |
| SK-80 | 4 to 5 | 0.455 | ~16.4 |
| SK-100 | 5 to 7 | 1.012 | ~30.0 |
Main Dimension:
| Model No | A | B | C | D | E | G | H | L | S | T | Y | R |
| SK-30 | 75 | 10 | 82 | 13 | 9 | 1/8'' | 132 | 68 | 6 | 50 | 27 | 1/4'' |
| SK-40 | 90 | 12 | 97 | 18 | 11 | 1/4'' | 162 | 78 | 10 | 60 | 34 | 1/4'' |
| SK-60 | 121 | 13 | 143 | 19 | 15 | 1/4'' | 215 | 100 | 10 | 60 | 48 | 1/4'' |
| SK-80 | 160 | 17 | 170 | 20 | 17 | 3/8'' | 260 | 140 | 14 | 90 | 70 | 3/8'' |
| SK-100 | 200. | 18 | 200 | 23 | 17 | 3/8'' | 318 | 160 | 18 | 90 | 70 | 3/8'' |
Installation Examples:
