| 起源の場所: | 中国 |
| ブランド名: | BRANDO |
| 証明: | None |
| モデル番号: | SGN,SGI |
| 最小注文数量: | 5個 |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 内箱、カートン、パレット |
| 受渡し時間: | 交渉 |
| 支払条件: | T/T、ウェスタンユニオン、マネーグラム |
| 供給の能力: | 100,000 PCS/月 |
| 製品名: | 冷蔵庫の視界ガラス | 接続口径: | 1/4"、3/8"、1/2」 |
|---|---|---|---|
| 繋がり: | フレア (int X ext) | メディア温度範囲: | -58〜175 °F |
| 最高使用圧力: | 500のpsig | 冷媒: | CFC,HCFC,HFC |
| ハイライト: | Sight glass type SGI SGN,Sight Glass SG SGN SGI,Danfoss Refrigeration Sight Glass |
||
Danfoss Type SGN SGI Low Pressure Sight Glass 1/4'' 3/8'' 1/2'' Flare int x ext
SG is sight glasses for low pressure application (Max Working Pressure 500 psig). SG is available with flare, solder and socket connections, and with and without moisture indicators. SG and SGR, without moisture indicator, are mainly used to indicate the condition of the refrigerant in the liquid line or the flow in the oil return line from the oil separator. SGI / SGN and SGRI / SGRN are equipped with sensitive indicators that reflects a color, which depends on the moisture content in the refrigerant.
Main Dimension of SG series Refrigeration Sight Glass:
|
Model
|
Connection Type
|
Connection Size
|
L
|
L1
|
H
|
H1
|
B1
|
φD
|
|
inch
|
||||||||
|
SGI / SGN 6
|
Flare
ext x ext
|
1/4''
|
2.638
|
-
|
0.945
|
0.551
|
0.551
|
1.063
|
|
SGI / SGN 10
|
3/8''
|
3.228
|
-
|
1.102
|
0.63
|
0.748
|
1.26
|
|
|
SGI / SGN 6
|
Flare
int x ext |
1/4''
|
1.811
|
-
|
0.945
|
0.551
|
0.63
|
1.063
|
|
SGI / SGN 10
|
3/8''
|
2.244
|
-
|
1.181
|
0.669
|
0.866
|
1.26
|
|
|
SGI / SGN 12
|
1/2''
|
2.323
|
-
|
1.181
|
1.181
|
0.945
|
1.26
|
|
|
SGI / SGN 6s
|
ODF x ODF
Solder
|
1/4''
|
3.976
|
0.276
|
0.945
|
0.551
|
0.551
|
1.063
|
|
SGI / SGN 10s
|
3/8''
|
4.685
|
0.354
|
0.945
|
0.551
|
0.551
|
1.063
|
|
|
SGI / SGN 12s
|
1/2''
|
5.748
|
0.394
|
1.102
|
0.63
|
0.748
|
1.063
|
|
|
SGI / SGN 16s
|
5/8''
|
5.748
|
0.472
|
1.181
|
0.709
|
0.866
|
1.063
|
|
|
SGI / SGN 22s
|
7/8''
|
6.811
|
0.699
|
1.457
|
0.827
|
1.063
|
1.26
|
|
|
SGI / SGN 6s
|
ODF x ODM
Solder |
1/4''
|
3.976
|
0.276
|
0.945
|
0.551
|
0.551
|
1.063
|
|
SGI / SGN 12s
|
5/16''
|
5.748
|
0.394
|
1.102
|
0.63
|
0.748
|
1.063
|
|
Technical Data of SG series Refrigeration Sight Glass:
