| 起源の場所: | 中国 |
| ブランド名: | BRANDO |
| 証明: | None |
| モデル番号: | DIN 43650A-T |
| 最小注文数量: | 5個 |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 内箱、カートン、パレット |
| 受渡し時間: | 交渉 |
| 支払条件: | T/T、ウェスタンユニオン、マネーグラム |
| 供給の能力: | 100,000 PCS/月 |
| 製品名: | DIN 43650のコネクター | 距離: | 18mm |
|---|---|---|---|
| 喧騒のタイプ: | DIN 43650フォームa | 形状: | 2+1GND、3+1GND |
| 定常電圧: | AC380V、DC300V | 保護クラス: | IP65 |
| Nomicalの流れ: | 10A | 接触抵抗: | ≤5mΩ |
| 最高のコンダクター セクション: | 3x1.5mmの² | 固定ねじ: | M3x28 |
| ハイライト: | DIN 43650 Form A Connector Transparent,Solenoid Coil Connector DIN43650A,MPM Solenoid Valve Connector DIN43650A |
||
DIN43650A Solenoid Valve Coil Connector 18mm Transparent DIN 43650 Type A
DIN 43650 solenoid connectors are durable valve connectors used across a wide range of industrial applications. They're not affected by voltage surges or electro-magnetic interference.
DIN 43650 solenoid connectors are available in three formats: Form A, Form B or Form C. They're made to function within certain voltage limits. There are also three gasket options available for DIN connectors: NBR Profile, NBR Flat or EPDM Flat, each with different characteristics. While NBR rubber is an oil-resistant material, EPDM rubber isn't as resilient against oils but can cope better with ozone, heat and adverse weather conditions. Male and female solenoid connectors are available and they're designed with different enclosure locks to choose from.
Technical Data of DIN43650A Solenoid Valve Connector:
|
DIN 43650 Type
|
DIN 43650 Form A
|
|
Termination Method
|
Screw
|
|
Contact Spacing
|
18mm
|
|
Number of Poles
|
2 Poles + Ground, 3 Poles + Ground
|
|
Current Rating
|
10A
|
|
Contact Resistance
|
≤5mΩ
|
|
Fixing Screw
|
M3x28mm
|
|
Max Conductor Size
|
3x1.5mm²
|
|
Gasket
|
NBR
|
|
Protection Class
|
IP65
|
|
Working Voltage
|
AC380V, AC220V, AC110V, AC24V, DC24V, DC12V
|
Dimension of DIN43650A Solenoid Coil Connector:
Product Video of DIN43650A Solenoid Valve Connetor:
More Solenoid Valve Coil Connectors for you to choose:
|
|
|
| DIN43650A | DIN43650B | DIN43650C |
|
|
|
| Waterproof | With Cable | Other |
More Solenoid Valve Coils for you to choose:
|
|
|
|
| Pneumatic Solenoid Valve Coil | Pulse Valve Solenoid Coil | Water Solenoid Valve Coil | Hydraulic Solenoid Valve Coil |
