| 起源の場所: | 寧波、中国 |
| ブランド名: | BRANDO |
| 証明: | None |
| モデル番号: | BB09030027 |
| 最小注文数量: | 200 |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 内箱、カートン、パレット |
| 受渡し時間: | 交渉 |
| 支払条件: | T/T、ペイパル、ウェスタンユニオン |
| 供給の能力: | 1 か月あたりの 250000 部分 |
| 製品名: | ソレノイドバルブコイル | 電圧: | 12VDC、24VDC、24VAC、110VAC、220VAC |
|---|---|---|---|
| 力: | 2W, 3W, 6W, 7W, 7.5W, 2.5VA, 5VA, 7VA, 8VA | コネクタ: | DIN43650A |
| 保護クラス: | IP65 | 絶縁クラス: | F、h |
| ハイライト: | Pneumatic Solenoid Valve Coil CNOMO,CNOMO Solenoid Valve Coil 12V,CNOMO Electrical Coil 24V |
||
CNOMO Pneumatic Solenoid Valve Coil 30mm 3/2 Way 12V 24V 110V 220V
This solenoid coil is same with AMISCO EVI 30/9, which is popularly used in CNOMO 30mm pneumatic solenoid valves. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC. Power: 2W, 3W, 6W, 7W, 7.5W, 2.5VA, 5VA, 7VA, 8VA. CNOMO direct solenoid valves are poppet valves 3 ways, ready to be assembled on the 06-05-80 CNOMO standard base. Available in the normally closed and normally opened version with or without manual operator. As standard, manual operator works with push and push+turn function in order to satisfy all needs.
Dimension & Data of Solenoid Valve Coil, Armature:
|
BRANDO Model
|
BB09030027
|
|
Voltage
|
12VDC, 24VDC, 24VAC,
110VAC, 220VAC
|
|
Power
|
2W, 3W, 6W, 7W, 7.5W,
2.5VA, 5VA, 7VA, 8VA
|
|
Other voltage and power can be customized
|
|
|
Connector
|
DIN43650B
|
|
Insulation Class
|
F, H
|
|
BRANDO Model
|
BAPC308932018
|
|
Function
|
3 Way Normally Closed
|
|
Plunger Tube Material
|
Brass
|
|
Seal Material
|
NBR, EPDM, FKM
|
|
Connection Type
|
Flange With O-ring Groove
|
Video of Solenoid Valve Coil:
