Solenoid Valve Armature Plunger Assembly Brass Tube OD 8mm 2/2 Way NC Normally Closed

Solenoid Valve Armature Plunger Assembly Brass Tube OD 8mm 2/2 Way NC Normally Closed

  • Solenoid Valve Armature Plunger Assembly Brass Tube OD 8mm 2/2 Way NC Normally Closed
  • Solenoid Valve Armature Plunger Assembly Brass Tube OD 8mm 2/2 Way NC Normally Closed
Solenoid Valve Armature Plunger Assembly Brass Tube OD 8mm 2/2 Way NC Normally Closed
商品の詳細:
起源の場所: 寧波、中国
ブランド名: BRANDO
証明: None
モデル番号: BAPC208026214
お支払配送条件:
最小注文数量: 1000
価格: 交渉可能
パッケージの詳細: 内箱、カートン、パレット
受渡し時間: 交渉
支払条件: T/T、ペイパル、ウェスタンユニオン
供給の能力: 月産300,000セット
連絡先
詳細製品概要
製品名: 電磁弁の電機子 プランジャー管材料: 真鍮
シール材質: NBR、EPDM、Viton ガイドチューブ外径:: 7.9mm
関数: 閉鎖した2方法普通 接続タイプ: O リング 槽付き フレンズ
ハイライト:

8mm OD Plunger Tube

,

Armature Stem

,

Solenoid Armature Plunger Tube Assembly

Solenoid Valve Armature Plunger Assembly Brass Tube OD 8mm 2/2 Way NC Normally Closed


This solenoid armature plunger is popularly used in 2 way normally closed solenoid valves. The armature assembly is the very important component of solenoid valve. When the working current passing through the coil, a magnetic field is generated around the coil. The electromagnetic force drives the moving iron core to overcome the resistance of the spring to move upward, and it is absorbed with the static iron core. When the coil is powered off, the electromagnetic force disappears, and the moving iron core is reset downward under the action of the spring force.


Dimension & Data of Solenoid Valve Armature:

Solenoid Valve Armature Plunger Assembly Brass Tube OD 8mm 2/2 Way NC Normally Closed 0

Model Number
BAPC208026214
Guide Tube Outer Diameter
7.9mm
Installation Height for Coil Assembling
21.4mm
Plunger Seal for Orifice Diameter
2.1mm
Guide Tube Material
Brass
Seal Material
NBR, HNBR, FKM, EPDM, Silicone, all available
Voltage
All range of AC and DC available
Position and Way
2/2 Way
Non-working Status
Normally Closed
Customized Service
Provided, welcome show us sample or drawing



BRANDO Solenoid Valve Armature Production:


More Solenoid Valve Armature Assembly for you to choose:

*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 60mm.

photobank (10)photobank (11)photobank (12)photobank (8)


*According to tube material: Brass, Stainless Steel

photobank (8)photobank (12)photobank (18)photobank (11)

*According to valve application:

1. Pulse Solenoid Valve Armature Assembly, 2. Water Solenoid Valve Armature Assembly, 3. Pneumatic Solenoid Valve Armature Assembly, 4. Refrigeration Solenoid Valve Armature Assembly, 5. Injector Rail Armature Assembly, 6. Air-Jet Loom Solenoid Valve Armature Assembly, 7. House Appliances Solenoid Valve Armature Assembly, 8. Automobile Solenoid Valve Armature Assembly, 9. Medical Solenoid Valve Armature Assembly, etc.

photobank (14)photobank (16)photobank (17)photobank (10)


Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing


Welcome to your any question and inquiry!
