| 起源の場所: | 寧波、中国 |
| ブランド名: | BRANDO |
| 証明: | None |
| モデル番号: | BAPC216049003 |
| 最小注文数量: | 1000 |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 内箱、カートン、パレット |
| 受渡し時間: | 交渉 |
| 支払条件: | T/T、ペイパル、ウェスタンユニオン |
| 供給の能力: | 月産300,000セット |
| 製品名: | 電磁弁の電機子 | プランジャー管材料: | ステンレス鋼 |
|---|---|---|---|
| 関数: | 閉鎖した2方法普通 | 応用: | Hennyのペニーのフライ鍋 |
| 合われたソレノイドのコイル モデル: | MP-C-011 | 合われた電磁弁モデル: | 18721、18724、17120、17121、29515、29547 |
| ハイライト: | MP-C-011 Armature Plunger,Henny Penny Solenoid Valve Armature Assembly,Henny Penny Solenoid Valve Repair Kit |
||
Henny Penny Solenoid Armature Assembly 18721 18724 17120 17121 29515 29547
This solenoid valve armature plunger is fitted for ASCO Red-Hat MP-C-011 solenoid coil, which is popularly used for Henny Penny fryer steam solenoid valves (18721, 18724, 17120, 17121, 29515, 29547). The armature assembly is the very important component of solenoid valve. When the working current passing through the coil, a magnetic field is generated around the coil. The electromagnetic force drives the moving iron core to overcome the resistance of the spring to move upward, and it is absorbed with the static iron core. When the coil is powered off, the electromagnetic force disappears, and the moving iron core is reset downward under the action of the spring force.
Dimension & Data of MP-C-011 Solenoid Coil, Armature:
|
BRANDO Model
|
MP-C-011
|
|
Connector
|
Flying Leads
|
|
Voltage
|
24VAC, 110VAC, 120VAC, 220VAC, 240VAC (50/60Hz) |
|
Insulation Class
|
F, H
|
|
Temperature Class
|
T, B
|
|
Fitted Solenoid Valve Model
|
18724, 18721, 29515, 29547, 17120, 17121
|
|
Application
|
Henny Penny Fryer
|
|
BRANDO Model
|
BAPC216049003
|
|
Function
|
2 Way Normally Closed
|
|
Plunger Tube Material
|
Stainless Steel
|
|
Shading Ring Material
|
Copper
|
|
Connection Type
|
Thread
|
|
Fitted Solenoid Coil
|
MP-C-011
|
|
Application
|
Henny Penny Fryer
|
Video of MP-C-011 Solenoid Valve Armature:
BRANDO Solenoid Valve Coils Production:
More Voltages of MP-C-011 Solenoid Coils for you to choose:
|
|
|
| 24VAC | 110VAC, 120VAC | 220VAC, 240VAC |
